ATTBLIME AB6 Scanning Spray


High performance for 3D metrology with the extra long service life

The AB6 3D scanning spray offers a reliable service life without tiresome re-spraying

  • Best spray with cyclododecane
  • SHC-system (Spray-head-change-system) for best-in-class efficiency
  • Free of ethanol and adamantane
  • High performance 3D Scanningspray
  • Scan time between 2 hrs and 6 hrs
  • Residue-free sublimation after 6 hrs to 10 hrs
  • No cleaning of scanning object required
  • Made in Germany
SKU: N/A Category: Tag:


ATTBLIME® AB6 is a scanning spray created to optimize 3D – scanning tasks. To achieve this an even and homogeneous spray layer is applied onto the surface. AB 6 is developed to be self-vanishing (sublimating) on the proven raw material cyclododecane, which we enhanced even further

The effective scanning time is 2 to 6 hours after the application of AB 6. The sublimation time, the time in which the spray dissolves, is around 6 to 10 hours. These times depend on the environmental conditions such as the component surface, room temperature, air circulation or even air humidity.

The scanning spray is free of ethanol and adamantane. AB6 adheres to all porous and non-porous surfaces such as textiles, wood, glass, painted surfaces, metal, plastic, stone, concrete and paper.

The spray cans are equipped with the unique SHC-system (spray-head-change-system), which allows the user to choose between vertical and horizontal, as well as wide and narrow exit angles, to optimize the spray layer and thus sublimation times. By having this unique SHC-system the spray layer is highly efficient by using the minimal amount of spray needed.

ATTBLIME AB6 is ideal for temporary matting of surfaces for optical 3D metrology without subsequent cleaning. Reference point marks can simply be stuck onto the treated surface.

Additional information

Weight 0.4 lbs
Quantity of Cans

1, 6, 12
